TVS Jupiter 125

TVS Jupiter 125 Disc

Ex-showroom Price Raebareli
Rs. 92,405*

Overview of TVS Jupiter 125 Disc

TVS Jupiter 125 Disc General Features
Engine Type Single cylinder, 4 stroke, Air cooled
Top Speed -
Engine Capacity -
Starting -
Brakes Disc
Gear Box CVT
Fuel Tank Capacity 5.1 L
Tyre Type Tubeless
TVS Jupiter 125 Disc Standard Features
Brakes
Pass Switch
Cooling System
ABS
CBS
Ebs
Body Graphics
Carry Hook
Shutter Lock
All Photos
360 View

TVS Jupiter 125 Disc Specification

TVS Jupiter 125 Disc Engine & performance
Engine Type Single cylinder, 4 stroke, Air cooled
Displacement 124.8
Mileage -
Bore 53.5 mm
Stroke 55.5 mm
Compression Ratio -
Maximum Power 8.15 PS @ 6500 rpm
Maximum Torque 10.5 Nm @ 4500 rpm
Starting Kick and Self Start
Maximum Speed -
TVS Jupiter 125 Disc Transmission
Gear Box CVT
Clutch -
Transmission Type Automatic
TVS Jupiter 125 Disc Fuel
Fuel Capacity 5.1 L
Supply System -
Fuel Reserve -
Fuel Gauge Digital
Digital Fuel Gauge -
TVS Jupiter 125 Disc Brake
Brakes Disc
Front Brake Disc
Rear Brake Drum
TVS Jupiter 125 Disc Tyre Size
Tyre Size

Front :-90/90 -12,

Rear :- 90/90 -12

Radial Tyres -
TVS Jupiter 125 Disc Wheel Size
Wheel Size

Front :-304.8 mm,

Rear :-304.8 mm

Wheel Base 1275 mm
TVS Jupiter 125 Disc Chassis and Suspension
Bike Suspension -
TVS Jupiter 125 Disc Frame
Chassis/ Frame -
TVS Jupiter 125 Disc Electrical
Ignition ECU Controlled Ignition
Battery Type -
Head Lamp -
Tail Lamp -
Turn Signal Lamp LED
TVS Jupiter 125 Disc Exterior Dimensions
Length 1852 mm
Height 1168 mm
Width 691 mm
Ground Clearance 163 mm
Saddle Height 765 mm
Kerb Weight 108 kg
Total Weight -
Weight Carrying Capacity -
Chassis/ Frame -
Wheel Base 1275 mm
